Bessey Parallel Jaw K-Body Revo Bar Clamp - 24 in. Capacity
High-Pressure Parallel Clamping for Woodworking
- Buy 2 for $66.61 each and save 8%
Bessey Parallel Jaw K-Body REVO Bar Clamp 24-in.
The Bessey K Body REVO Parallel Jaw Bar Clamp is a powerful, versatile woodworking clamp designed for precise 90° clamping and high-pressure assembly applications. With large parallel clamping surfaces and a rugged construction, it delivers secure, even pressure across cabinet doors, panels, frames, furniture components, and other woodworking projects.
The 24-in. clamping capacity provides plenty of reach for larger workpieces, while the parallel jaws help keep surfaces accurately aligned during glue-ups and assembly. The clamp can also be converted to a spreader without tools, making it a practical addition to any professional or home woodworking shop.
Precise, Parallel Clamping
The K Body REVO is designed to clamp and spread workpieces while keeping the jaws precisely parallel to one another. The large clamping surfaces are positioned perpendicular to the rail for excellent contact and stability. This design makes it easy to align corners, recessed edges, pointed surfaces, and rounded workpieces.
- Large parallel clamping surfaces provide excellent workpiece contact.
- Clamps workpieces accurately from behind or along the side of the rail.
- Three removable pressure caps help protect delicate surfaces.
- Pressure caps resist glue, paint, and grease solvents and can be removed for cleaning or replacement.
- Integrated workpiece supports help keep materials away from the clamp rail.
Up to 1,700 lbs. of Clamping Force
Built for demanding woodworking applications, the Bessey K Body REVO can deliver clamping force up to 1,700 lbs. The metal-reinforced plastic housing provides strength and durability, while the optimized sliding arm with double slide protection helps maintain the selected clamping position and reduces unwanted movement when the clamp is not under pressure.
- Up to 1,700 lbs. of clamping force.
- Metal-reinforced plastic housing provides durable performance.
- Optimized sliding arm features double slide protection.
- Securely maintains the selected clamping position.
Ergonomic Handle for Comfortable Clamping
The ergonomically shaped, symmetrical two-component handle provides a comfortable grip and makes it easy to apply substantial clamping force. A built-in steel hex socket allows additional force to be applied with a hex key or suitable driver when needed, with a maximum torque of 17 Nm.
Protective Rail and Workpiece Features
Protective components help keep the clamp and workpiece in good condition during glue-ups and other messy woodworking operations. Impact-resistant polyamide rail protection pieces help prevent glue from dripping onto the rail, while workpiece supports provide clearance between the material and clamp rail.
- Impact-resistant polyamide rail protection pieces help shield the rail from glue.
- Removable pressure caps are easy to clean or replace.
- Workpiece supports prevent direct contact between the workpiece and rail.
- TK-6 table clamps can be used to secure the rail protection pieces to a work surface.
Quickly Converts to a Spreader
The K Body REVO offers more than traditional clamping. The removable end clip helps keep the clamp parallel to the work surface and can be removed to reverse the sliding arm. This allows the clamp to be converted from a clamp to a spreader without tools, providing additional versatility for cabinet installation, furniture assembly, and woodworking projects.
- No-tool conversion from clamp to spreader.
- Removable end clip helps maintain parallel positioning.
- Reversible sliding arm provides spreading capability.
Versatile Accessories and Applications
The K Body REVO platform is compatible with a variety of accessories designed to expand its usefulness in the workshop. Optional accessories include a tilting adapter, frame press set, clamp extension, and table clamp system. These accessories allow the clamp to adapt to specialized assembly and workholding applications.
Bessey K Body REVO 24-in. Clamp Specifications
- Model: BT-3724
- Clamping Capacity: 24-in.
- Clamping Force: Up to 1,700 lbs.
- Maximum Torque: 17 Nm
- Jaw Type: Parallel jaw
- Function: Clamping and spreading
- Pressure Caps: Three removable, glue-resistant caps
- Handle: Ergonomic two-component handle with steel hex socket
Ideal for Cabinetmaking, Furniture Building, and General Woodworking
The Bessey K Body REVO 24-in. Parallel Jaw Bar Clamp is an excellent choice for cabinetmakers, furniture builders, woodworkers, and serious DIYers who need accurate alignment and substantial clamping pressure. Its parallel jaws, durable construction, protective features, ergonomic handle, and tool-free spreading conversion make it a versatile solution for everything from panel glue-ups and cabinet assembly to frame construction and general workshop clamping.
| BRAND | BESSEY |
|---|---|
| THROAT (CLAMP REACH) | 3-3/4 in. |
| CLAMP CAPACITY | 24 in. |
| QUANTITY | (1) Each |
| SKU | BT-3718 |
| Prop 65 |
|
Proposition 65 (formally titled "The Safe Drinking Water and Toxic Enforcement Act of 1986") is a California law that has been in effect since 1986 to promote clean drinking water and keep toxic substances that cause cancer and birth defects out of consumer products. It is administered by Cal/EPA's California Office of Environmental Health Hazard Assessment (OEHHA). Proposition 65 regulates substances listed by California as causing cancer or birth defects or other reproductive harm in two ways. The first regulatory arm of Proposition 65 prohibits businesses from knowingly discharging listed substances into drinking water sources, or onto land where the substances can pass into drinking water sources. The second regulatory arm of Proposition 65 prohibits businesses from knowingly exposing individuals to listed substances without providing a clear and reasonable warning.
BESSEY branded products do not, to the best of our knowledge, expose individuals to harmful substances as listed by the Cal Prop 65 Legislation.
WARNING: Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
