Kreg Precision Router Lift

Kreg® Precision Router Lift

No more reaching under the table to adjust or change bits!

Using the lift’s crank to adjust the height of your router, adjustments can be made easily and precisely from above the table. Once the height has been approximately set, fine-tuning is made possible with a built-in micro-adjustment scale. Also, the micro-adjust scale can be zeroed out at any point to make exact bit height changes.

FEATURES:

• Machined-Aluminum Router Carriage Accepts 20+ popular routers without requiring pads or adapters.
• Fits all Kreg router tables and many competitive brands.
• Above-the-table setup changes for table-mounted routers.
• Above-table collet access allows fast, easy, above-table bit changes
• Precision indexing ring with micro-adjust scale simplifies bit height changes. Micro-adjust dial with fractional markings every 1/64" and hash marks every .002" in between. One full revolution equals 1/16 in.
• 3/8 in. x 9-1/4 in. x 11-3/4 in. (9.5mm x 235mm x 298mm) hard-anodized aluminum plate won’t sag, resists scratches
• Bearing-guided carriage provides smooth operation

Includes:

• Router Lift
• Adjustment Crank
• Level-Loc Reducing Rings: 25mm, 13⁄16 in. (30mm), and 25⁄8" (67mm)
• Ring Wrench
• Stainless Steel Starting Pin
• Owner’s Manual

COMPATIBLE ROUTERS:

• Bosch 1617, 1618 - 3.5 in.
• Craftsman 17543, 17540, 28190 - 3.5 in.
• DeWalt 610, 616, 618 - 3.5 in.
• Felisatti RF62 - 3.675 in.
• Hitachi M12VC, KM12VC - 3.267"
• Makita 1101 - 3.218"
• Milwaukee 5615, 5616, 5619 - 3.32"
• Milwaukee 5626 - 4.143 in.
• Porter-Cable 690, 890 - 3.5 in.
• Porter-Cable 7518 - 4.2"
• Ridgid R29302 - 3.625 in.

If your router is not on the list, please call customer service so we can determine whether your router will fit.
