Euro Ltd. - Concealed Hinge Installation Tool
Euro Ltd. - Concealed Hinge Installation Tool
The Euro-Jig represents an advancement in locating concealed hinge mounting plates of all brands, by being able to locate for hinges of different cup sizes.
The two polycarbonate locating templates mounted to the aluminum rails are provided with a V notch to match the location of the hinges on the door, by referencing of the hinge arm. This produces perfect results every time.
The Euro-Jig works for overlay and inset positioning and can locate mounting plates for doors up to 50" tall.
Designed to be used with the Euro-Bit self centering drilling tool.
Specifications
- Rails: Extruded Aluminum
- Bushings: Steel
- Rail Connectors: Chrome Steel
- Knobs: Plastic, with Steel Studs
- Color: Aluminum, Natural Plastic, Gray
- Finish: Aluminum, Anodized
- Euro-Bit Guide Bushing: Ceramic Nylon
- Size: 4" x 1.5' D x 28.75" L
| BRAND | Euro Ltd |
|---|---|
| QUANTITY | (1) Each |
| SKU | EU-3212 |
| SPECS: | |
| Prop 65 |
|
WARNING: Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
