#7 x 2-1/4 in. Trim Head, 316 SS, Star, Tan 04 - 12.5 Lbs
7 x 2-1/4-in. Trim-Head Decking Screws, 316 SS, Tan 04 — Qty:1750
These 7 x 2-1/4-in. Trim-Head Decking Screws provide a clean, low-profile fastening solution for wood decking and select PVC decking applications. Made from Type 316 stainless steel, they offer excellent corrosion resistance for demanding exterior environments, including marine and seaside applications where moisture and salt exposure are a concern.
The small trim-style head creates a less noticeable appearance on the decking surface, while the Tan 04-painted head helps the fastener blend into dark decking materials for a more concealed finish. The screws feature a T15 6-lobe drive for reliable bit engagement, improved driving control, and long bit life.
Fast, Secure Decking Installation
A Type-17 point helps the screw start quickly and efficiently, while coarse threads extending along approximately two-thirds of the shank draw decking and other materials tightly against the framing. This combination provides dependable holding power and smooth installation in common decking applications.
Key Features
- Type 316 stainless steel: Provides superior corrosion resistance for exterior, marine, and seaside applications.
- Trim-style head: Creates a smaller, less noticeable head on the decking surface.
- Tan 04-painted head: Provides a concealed appearance and helps the fastener blend with dark decking materials.
- Type-17 point: Promotes fast starts and efficient driving.
- Coarse threads: Threads extending along approximately two-thirds of the shank help pull decking tightly against the framing.
- 6-lobe drive: T15 Star drive provides excellent drive control and helps promote long bit life.
- Predrilling recommended: Predrill near board ends to help reduce the risk of splitting.
- Decking coverage: A 350-count package is designed to fasten approximately 100 sq. ft. of decking when using 6 in. nominal-width boards installed on 16 in. on-center joists.
Applications
- Wood decking
- Select PVC decking materials
- Exterior decking projects
- Marine and seaside decking applications
- Other exterior applications requiring enhanced corrosion resistance
Specifications
- Size: #7 x 2-1/4-in.
- Material: Type 316 Stainless Steel
- Head Style: Trim Head
- Head Color: Tan 04
- Drive: T15 6-Lobe (Star)
- Thread Type: Coarse
- Point: Type-17
- Approximate Head Diameter: 0.230 in.
- Replacement Bit: BIT15T-2-R2
- Package Quantity: 1750 screws
Built for Exterior Decking
With Type 316 stainless steel construction, a corrosion-resistant Tan 04-painted finish, trim-style head, fast-starting Type-17 point, and T15 6-lobe drive, these decking screws are designed for clean-looking and dependable fastening in demanding exterior environments.
| SIZE (#8, #10 ...) | #7 |
|---|---|
| LENGTH | 2-1/4 in. |
| MATERIAL | Stainless Steel, 316 |
| COUNTERSINK NIBS | Without Nibs |
| RECESS TYPE | Star / Torx |
| HEAD | Trim |
| POINT TYPE | Type 17 |
| BRAND | McFeely's Head Coated |
| RECESS SIZE | T-15 |
| QUANTITY | Keg |
| Color | Tan 04 |
| Unthreaded Length | 1 in. |
| Threaded Length | 1-1/4 in. |
| Head Diameter | 7/32 in. |
| Unthreaded Shank Diameter | 1/8 in. |
| RoHS Compliant? | No |
| SKU | 0722-TT6-TN04-K |
| SPECS: | SPECS:
|
| Prop 65 |
|
WARNING: This product can expose you to chemicals such as copper, nickel, lead or chromium which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
WARNING: Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood.
